Ives FB358.US26D Manual Flush Bolt | Relcross Door Controls

Manual Flush Bolt (Timber Doors) - for use at the leading edge of one leaf of a pair of doors (top or bottom).

When the active door is opened, the lever can be moved to the ‘up’ position, retracting the bolt and opening the inactive leaf. When the inactive leaf is closed, the lever can be moved to the ‘down’ position, projecting the bolt into the strike and securely locking the inactive leaf
Reduces installation costs; requires only simple router mortice at the top and bottom corners of doors
Non-handed
Bolt tip 13mm diameter
Bolt throw is 19mm with a 22mm vertical adjustment
Bolt backset is 19mm
Not available for rebated door installations
DP1 & DP2 optional dust proof strike available

Correct hardware specification on plain meeting stile pairs of doors is vital to maintain integrity. Flush bolts provide a means to ensure fixed leaves are held in position (manual) or released (automatic) when the active leaf of a pair of doors is opened. Best suited to perimeter & internal rated pairs of hollow metal doors where alternative locking hardware may be unsuitable.
